Bag Filter
Invent Valves manufactures high quality bag filter housings. Bag filters are used in applications where you require fine filtration. We have Single Bag and multiple Bag Housings and our housings are compatible with mostly available bags (PP collar, SS collar, etc). we put a lot of emphasis in design to ensure zero bypass and perfect sealing of bags.
Bag housings suitable unto 12 bags, for more information contact us right now.
Features:
- Fine Filtration Capacity
- Housings suitable for most types of bags (PP collar, SS collar,etc)
- Eye Bolt Design for Top Flanges
- “O” ring Construction
- Same Housing suitable for Stainless steel Elements
Options:
- Hinged cover or davit assembly for easier maintenance
- Drain/Vent Valves
- P Tapings / Gauge
- Steam jacket for highly viscous fluids
- Rotated or offset nozzle placement
- High pressure capabilities
- Coatings and linings available upon request
Materials Of Construction Gate Valve
| No. | NO DECREllON | MATERIAL OF CONSTRUCTION | |
|---|---|---|---|
| 01 | SHELL | SS 304/ 304L | SS 316/ 316L |
| 02 | SHELL RANGE | SS 304/ 304L | SS 316/ 316L |
| 03 | COVER FLANGE | SS 304/ 304L | SS 316/ 316L |
| 04 | ‘O’ RING | NITRILE / NEOPRENE / VITION / SILICON / EPDM | |
| 05 | IN-OUT NOZZLE | SS 304/ 304L | SS 316/ 316L |
| 06 | NOZZLE FLANGE | SS 304/ 304L | SS 316/ 316L |
| 07 | DISHEND | SS 304/ 304L | SS 316/ 316L |
| 08 | BAG | PP | |
| 09 | BAG PRASSURE RING | SS 304/ 304L | SS 316/ 316L |
| 10 | SUPPORT & NUT | SS 304/ 304L | SS 316/ 316L |
| 11 | ‘O’ RING | NITRILE / NEOPRENE / VITION / SILICON / EPDM | |
| 12 | EYE BOLT & NUT | ASTM A 193/194 GR. B7/2H (ZINC PLATED) | |
| 13 | DRAIN | SS 304/ 304L | SS 316/ 316L |
| 14 | VENT | SS 304/ 304L | SS 316/ 316L |
| 15 | HANDLE | SS 304/ 304L | SS 316/ 316L |
| 16 | LEG | SS 304/ 304L | SS 316/ 316L |
