Fabricated Simplex Basket Strainers

Basket Strainers feature top removal of the screen. The screen is in the form of a basket, with a lifting handle, so that all particulate captured and retained by the screen can be easily removed for disposal. They are intended for applications where large amounts of solids particulate are expected and where the clean-out will be frequent. For easily flushable solids, a modified cone bottom basket can be tilted with automatic or manual blow-down through drain port.
This will allow clean-out without removal of the screen, and without interrupting the flow process.

Flanged End Connections. Pressure ratings are ANSI 150# to 600#. Standard body materials offered are Cast Iron, Ductile Iron, Cast Steel, Stainless Steel, Chrome-Moly and Bronze. Various Perforations, Mesh or Perforation Mesh combinations baskets are available to meet your process requirements. Invent Basket Strainers can be equipped with Bolted Covers, Hinged Covers, Clamped Covers, a Davit Lifting Device or other Lifting Device to make removal of large heavy covers safe and efficient. Widespread list of options are available. For more information contact us right now.

Size: 1”- 24” (Flanged ends, Butt weld ends)

Rating: 150# to 2500#
